Hydraulic rock splitter

  • Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter
  • Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter
  • Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter
Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock SplitterHydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock SplitterHydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter

Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter

  • The Rock Splitter is a larger Rock Splitter.Used on excavators, cranes or other carriers with hydraulics, applications include the breaking of rocks and concrete foundations.
  • The maximum splitting force is 4000T
  • Product description: Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power Hydraulic Rock Splitter,Non Vibration Rock Breaking Method by Superdrill Rock splitter uses the multiple hydraulic pistons push
  • INQUIRY Email Whatsapp

Hydraulic Breaker Excavator-mounted Splitter Excavator Driven Big Power hydraulic rock splitter



Hydraulic Rock Splitter for   Excavator - Technical Specifications


Perfect for demolition, mining, and rock excavation   projects


Model

Splitting Length

Drill Hole Depth

Working Pressure

Splitting Force

Crack Width

Alignment System

Weight


HE200

750mm

1400mm

24-35 MPa

1800-2100 Tons

35mm

Manual Chain

500 kg


(Made to Order)


1000mm

1600mm

24-35 MPa

1800-2100 Tons

35mm

Hydraulic

530 kg


JQ220

750mm

1400mm

24-35 MPa

2100-2300 Tons

35mm

Manual Chain

600 kg


(Made to Order)


1000mm

1600mm

24-35 MPa

2100-2300 Tons

35mm

Hydraulic

630 kg


JQN50

750mm

1400mm

24-35 MPa

2600-4300 Tons

30mm

Manual Chain

820 kg


(Made to Order)

1000mm

1600mm

24-35 MPa

2600-4300 Tons

30mm

Manual Chain

860 kg


JQ300

750mm

1400mm

24-35 MPa

3750-5500 Tons

30mm

Manual Chain

930 kg


(Made to Order)


1000mm

1600mm

24-35 MPa

3750-5500 Tons

30mm

Manual Chain

970 kg


Application
On sites where there is a restriction or ban on the use of hydraulic impact hammers or conventional blasting methods.
In downtown core areas where there are by laws regarding noise and dust pollution.
Job sites near to electrical supplies, gas mains, water mains, or other services that can be adversely affected by vibration and fly rock.
Under, in, or beside historic buildings, that can be damaged by less controlled methods.
Excavating narrow trenches in rock, or concrete, dedicated to service lines such as gas, electricity, water and sewage.
1.Hydraulic splitter work under the statically hydraulic environment can be controlled, it will not bring any dangerous compare to explosion, impact demolition.


2.Environmental protection:


Hydraulic splitter can be continuous working to complete splitting process in several seconds, the cost of function and maintenance is very low, extremely effective and economical.

4.Operation:


It is difference to traditional demolition methods, hydraulic splitter can ensure division direction, shape and size of remove part in advance, thus the division and dismantling are in high precision.

Hydraulic splitter is compact, light, high split force, can work convenience indoor or narrow ground, also can work under the water.
