DTH hammer

6 inch Halco DTH hammers

Hammer Size:1” to12”
Product description: 6 inch Halco DTH hammers user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. Halco
INQUIRY Email Whatsapp

Halco 6" DTH Hammer Range

Hammer	Mach 60	Dominator 600	Dominator 600	Dominator 600
Part Number	600035	600151	600094	600152
Shank	Halco Mach 60	Halco Mach 60	IR DHD 360	Sandvik Mission A53-25
Top Thread	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin
Hammer Flat Size	90mm (3.544”)	90mm (3.544”)	101mm (3.977”)	101mm (3.977”)
Weight	89 kg	89 kg	89 kg	89 kg
Outside Diameter	138mm (5.433”)	139mm (5.472”)	139mm (5.472”)	139mm (5.472”)
Make Up Length	1095mm (43.110”)	1208mm (47.559”)	1208mm (47.559”)	1208mm (47.559”)
Rec. Min. Thrust	500 kg (1100 Lbs)	500 kg (1100 Lbs)	500 kg (1100 Lbs)	500 kg (1100 Lbs)
Rec. Max. Thrust	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)

Hammer	Super Dominator 600	Super Dominator 650	Super Dominator 650	Super Dominator 650 HD QL 60
Part Number	600272	600213	600233	600316
Shank	IR DHD 360	IR DHD 360	Sandvik Mission A53-15/SD6	IR QL 60
Top Thread	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin
Hammer Flat Size	101mm (3.977”)	101mm (3.977”)	101mm (3.977”)	101mm (3.977”)
Weight	100 kg	104 kg	104 kg	100 kg
Outside Diameter	140mm (5.511”)	146mm (5.748”)	146mm (5.748”)	146mm (5.748”)
Make Up Length	1139mm (44.842”)	1139mm (44.842”)	1139mm (44.842”)	1043mm (41.07”)
Rec. Min. Thrust	500 kg (1100 Lbs)	500 kg (1100 Lbs)	500 kg (1100 Lbs)	500 kg (1100 Lbs)
Rec. Max. Thrust	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)	1500 kg (3300 Lbs)

Hammer	GW 600	GW 600 HD
Part Number	600397	600398
Shank	IR QL 60	IR QL 60
Top Thread	3 1/2” Api Reg Pin	3 1/2” Api Reg Pin
Hammer Flat Size	101mm (3.976”)	101mm (3.976”)
Weight	86 kg	100 kg
Outside Diameter	140mm (5.512")	146mm (5.748")
Make Up Length	1035.15mm (40.754”)	1035.15mm (40.754”)
Rec. Min. Thrust	500Kg (1100Lbs)	500Kg (1100Lbs)
Rec. Max. Thrust	1500Kg (3300Lbs)	1500Kg (3300Lbs)

Halco hammers are user friendly and reliable. They are built using the highest quality heat treated nickel chrome alloy steels thereby delivering exceptional productivity and durability. Halco strives for continual improvement and utilizes a specially designed comprehensive and coordinated quality system to ensure customer satisfaction through top quality products.
