TCI Tricone Bit

  • 6 3/4 inch 171.5mm IADC 537 tci tricone bits
  • 6 3/4 inch 171.5mm IADC 537 tci tricone bits
6 3/4 inch 171.5mm IADC 537 tci tricone bits6 3/4 inch 171.5mm IADC 537 tci tricone bits

6 3/4 inch 171.5mm IADC 537 tci tricone bits

  • Size of tricone bit 6 3/4 inch 171.5mm
  • Thread Connection 3 1/2 API reg pin
  • Single gross weight: 26.000 kg
  • Single package size: 23X19X37 cm
  • Product description: 6 3/4 inch 171.5mm IADC 537 tci tricone bits,Using a Tri Cone Over Other Drill Bits,These roller cone drill bits are designed to go to extreme depths in extreme conditions and in situations where th
  • INQUIRY Email Whatsapp

6 3/4 inch 171.5mm IADC 537  tci Tricone Bits

Samples: IADC 617

$980.00/Piece | 1 Piece (Min. Order)

Basical Specification
Size of tricone bit
6 3/4"  171.5mm
Thread Connection
3 1/2" Reg pin
IADC CODE
537
Bearing type
rubber /metal o-ring journal bearing
Operating Parameters
Recommended Make up torque
8.5~12.2 KN.M
WOB (Weight On Bit)
0.70~1.2 KN/mm
Rotary speed
70~40 r/min
Formation
Medium hard with high compressive strength and high abrasiveness ,such as limestone ,dolomite,sandstone and chert ,etc
